Play Differently Model 1
Allen & Heath XONE:96
Analogue DJ Mixer
A new, uncompromising analogue DJ mixer, destined to be the heart of your creativity, Xone:96 takes the legendary soul of the acclaimed Xone:92 and redelivers it, enhanced, and with state-of-the-art digital connectivity.
It’s all here. The huge, detailed, space-shaking analogue sound that only Xone delivers. A refined, precision 4-band EQ. Unrivalled dual Xone:VCF filters with CRUNCH harmonic distortion. And a dual 32-bit USB soundcard (24 Channels @ 96kHz) with Traktor Scratch certification right out of the box.
Two dedicated FX sends, four stereo input channels (with 4-Band EQ), two stereo input channels with all new 3-Band Parametric EQ + two auxiliary stereo return channels. And a separate master insert for your outboard hardware.
- Brand
- Category
- Model
Find Alternatives
Specification
| Type | Analogue |
| Channels | 6 + 2 |
| EQ | Channel 1-4, 4-Band EQ, Channel A-B, 3-Band Parametric EQ |
| Send/Return I/O | 2 x 1/4″ TRS Send, 4 x 1/4″ TRS Return, 1 x LN/Hi-Z Switch (SND1/RTNA) |
| Filter | 2 x VCF Filter, HPF / BPF / LPF, Adjustable Frequency & Resonance, Assignable CH 1-4 + CH A-B, CRUNCH (Controlled Harmonic Signal Distortion) |
| Faders | 60mm VCA / Replaceable (Channel), 3 Types (Channel Curve), 9 Segment LED (Channel Meter), InnoFADER / 45mm VCA / Replaceable (X-Fader), 3 Types (X-Fader Curves) |
| Inputs | 4 x RCA (CH 1-4) 4 x 1/4″ TRS (CH A-D) Mono/Stereo, 4 x RCA (CH 1-4) LN/PH Switch for DVS( Phono), 6 x USB (CH 1-4 + CH A – CH B), 2 x XLR (Mic) |
| Outputs | 1 x XLR (Balanced) (Master Output ), 1 x 1/4″ TRS (Balanced) (Master Output 2), 1 x 1/4″ TRS (Balanced) (Booth Output), 1 x RCA (Un-balanced) (Record Output) |
| AC Mains | 100 to 240V, AC 50/60Hz, Consumption 45W max |
